Double Deep Reach Truck CQD-X

Product Features

Double-deep reach forks, with forks that reach forward and backward, to load and move pallets, suitable for non-standard pallets. Work in a narrow aisle.
Telescoping distance: 1200 mm, the maximum reach depth is 1500 mm.
Full AC Drive system, small size, light weight, maintenance-free, no carbon brush. Works stably and efficiently.

Characteristics	Model No.		CQD15X-45
	Power Type		Electric
	Operation Type		Stand Type
	Load Capacity	Q(kg)	1500
	Load Center	C(mm)	500
	Loading Distance, Centre Of Drive Axle To Fork	Y(mm)	1562
Weight	Service Weight(with Battery)	kg	3540
Wheels, Chassis	Wheel Type		PU
	Drive Wheel	∅×w(mm)	382*142
	Front Wheel	∅×w(mm)	145*100
	Balance Wheel	∅×w(mm)	180*76
	Wheel Qty (Front, Drive, Balance)		4/2X/2
	Front Wheel Base	b10(mm)	1562
Dimensions	Mast Height Lowered	h1(mm)	3050
	Lifting Height	h3(mm)	4500
	Max. Lift Height	h4(mm)	5585
	Height Of Overhead Guards	h14(mm)	2280
	Overall Length (With/Without Fork, Fork Retracted)	l2(mm)	2410/1977
	Overall Width	b1(mm)	1390
	Fork Size	s/e/l(mm)	351001070
	Fork Spread	b5(mm)	210-680
	Min. Ground Clearance	m2(mm)	65
	Aisle Width For Pallet 1000*1200 Crossways	Ast(mm)	2835
	Min. Turning Radius	Wa(mm)	1854
	Fork Reach Distance	L(mm)	1200
Performance	Trave Speed(Unladen/Laden)	km/h	7/6.5
	Lifting Speed(Unladen/Laden)	m/s	0.330/0.245
	Lower Speed(Unladen/Laden)	m/s	0.260/0.325
	Service Brake		Electromagnetic
Motor, Charger	Drive motor	kw	4.5
	Lift motor	kw	6.3
	Battery Type		Lead Acid
	Battery voltage/nominal capacity	V/Ah	48/300
	Charger	V/A	48/40
Other	Type of Drive Control		Hall Accelerator
Note: The parameters above are for reference only and are subject to technical change without notice. Thanks for your understanding.
